CHASSIS

Built to ADR62/01 standards
Heavy duty leaf spring suspension with beam axles #
Single Spare wheel mounted on rear Bumper Bar 3000kg Heavy Duty 50mm ball coupling
Integrated Handbrake
100 x 50mm Rear bumper bar with 3 stays
Bike Rack Plate
Optional Tandem Axles maybe available

EXTERNAL APPOINTMENTS

Annexe light (LED) x 1
A&E Dometic 8500 series Roll out Awning
Adjustable corner stabiliser legs
Heavy duty galvanised fully sealed wheelarches
Galvanised steel water tank protectors
2 x 6kg LPG Gas Cylinders with Changeover valve
Mains Pressure water connector and pressure reduction valve
Dometic Tinted Acrylic windows (Double Glazed) - integrated blinds and Flyscreens
Premium Security Door with steel mesh
Front Galvanised tunnel boot locker with external side access door and light
Pull Out Step

INTERNAL APPOINTMENTS

Flikmixer tap
High Quality "Pillow" Upholstery
Luxury Double size innerspring mattress (Lift up base on Gas struts)
Four Seasons roof hatch (Not available in Pop - Top)
Acrylic or Timber internal furniture & cabinets
High grade vinyl flooring
Positive locking Quick-pull catches to cupboards & drawers
Soft close drawer runners
Laminex square edged benchtops and table
Cafe Dinette with tri-fold table
Mirrored Wardrobes with drawers below

APPLIANCES

Externally vented 12v Rangehood
Deluxe 3 Gas/1 Electric Stove, Grill
Dometic 3 way 90lt Fridge
Radio Single DIN CD/MP3/USB + Bluetooth with 2 x internal speakers
Winegard sensar HV TV Wind-up TV antenna (Vertical & Horizontal Polorization)

ELECTRICAL

All Electrical installations compliant with AS3000 & AS300
240/12v Smart Charger
50amp anderson plug & Heavy duty trailer wiring (Individually fused)
Deep cycle AGM batteries (1 x 120 AH)
Roof Mounted 150w Solar panels x 1 & Regulator
12v LED Internal Roof Lights
12v LED Internal Down Lights
12v LED Bed lamps
12v Power points - 1 internal, 1 external
Ample 240v Double Power points
240v External and 12 volt External power outlet
External TV connection point

PLUMBING

Gas plumbed to AS5601
Water supply system plumbed to AS3500
Mains tap on drawbar
12v Water pump, accumulator & mains pressure connections
Gas/Electric Hot water service
28ltTemperature limiting valve for Hot water
2 x 65lt Water storage tanks with galvanised guards, lockable fillers & water level gauges

Rear Cutaway (Increased departure angle) #
Twin Spare wheel mounted on rear Bumper Bar *
Spare wheel mounted on Ratchet under van #
2 x Front mounted Jerry can holders *
Steel framed shade mesh stoneguard on drawbar *
Aluminium Mesh in drawbar A-frame for storage *
100 x 50mm Rear bumper bar with 4 stays *
Wheels sized to suit tow vehicle (available for some vehicles) *
Breakaway Emergency brake safety switch *
Dexter stability control (DSC) *
High Level Ancillery Stop/Tail/Indicator lamps *
Ancillery Indicator lamps midway along each side of van *
Rear vision camera, car screen & Heavy duty connection cable *
External aluminium Composite Panel smooth (White or Silver) *

Annexe light (LED) x 2 *
Externally accessed generator locker (built in) *
External Checkerplate Box on Rear Bumper Bar *
Pressurising Rooftop Scupper vent *
2 x 9kg LPG Gas Cylinders with Changeover valve *
UV Protected Poptop skirt with 4 x Large zip vents and Flyscreens #
External Picnic table *
Genuine Leather Upholstery *
Luxury Single size innerspring mattress (Lift up base on Gas struts)
L-Shaped dinette converts to extra bed #
Bifold table at café seating #
Skylight Hatch #

12v Sirocco fan/s *
Blockout Drawer Curtains and Timber/Fabric Pelmets *
Plaza Plus Holland External Door Blind *
Hardwood edged Benchtops and Table *
Microwave oven *
Dometic 3 Way 190lt Upright Fridge/Freezer #
IBIS reverse cycle airconditioner *
Webasto Diesel heater with External 10lt fuel tank *
Dometic E2400 Gas Heater *
24" Flat screen TV with inbuilt DVD player *
Radio Double DIN CD/MP3/USB + Bluetooth with 4 x Internal Speakers & 2 x External speakers *
Deep cycle AGM batteries (2 x 120 AH) *
Lithium-iron-phosphate (LiFePO4) Battery Systems (system available from 100AH - 400AH) *
Pure Sinewave Inverter 600-3000w *
Roof Mounted 150w Solar panels x 2 *
External solar input for connection of freestanding solar panel *
Fully Automatic satellite TV Receiver & dish *
2nd 12v Water Pump, accumulator dedicated to 1 x water tank *
2 x 95lt Water storage tanks with galvanised guards, lockable fillers & water level gauges #
1 x 95lt Grey water tank *
Water filtration system *
Gas Bayonet *

* Optional Extra
# Available/Optional - Some models only
